Attributes
Weight：80/100/120/155/160/170/180/185/200/205/220/240/440g/m2
Thickness: 0.11mm,0.15mm,0.2mm,0.22mm,0.24mm,0.25mm,0.26mm,0.28mm,0.3mm,0.42mm
Note:
1. Normally Regularly on Stock
2. MOQ and production details have to be discussed
3. Weight and Weave Pattern(plain/twill/satin/UD/jacquard/hybrid)can be customized
4. Resin types can be referred to the parameter
Aramid Prepreg is a composite where aramid fibers are pre-impregnated with resin, merging aramid’s high strength and heat resistance with resin’s bonding. Lightweight and impact-resistant, it’s ideal for high-performance structural applications requiring durability under stress.
Keywords：Aramid Prepreg、composite、aramid fibers、resin、high strength、heat resistance、lightweight、impact-resistant
Description
| FOB Price: Contact us for pricing | Port: NINGBO, SHANGHAI. OINGDAO |
| Brand: weinuo | Delivery:7-30 days after confirmatior |
| Payment: 30% Deposit by T/T and the balance before shipment or against the copy B/L | |
| Shipping: EMS, FedEx, DHL, UPS, By Air & By Sea | |
Aramid Prepreg combines woven or unidirectional aramid fibers with a curable resin matrix, engineered for controlled performance. Its pre-impregnated form ensures uniform fiber-resin distribution, simplifying fabrication of complex parts. Withstanding high temperatures and absorbing impact energy, it’s critical in aerospace, defense, and racing, where weight, strength, and reliability intersect.
Feature：
High impact energy absorption：
Excels at dissipating impact forces, making it ideal for protective and crash-resistant structures.
Thermal stability：
Maintains mechanical properties at elevated temperatures, outperforming many materials in heat-exposed environments.
Controlled processability：
Pre-impregnated resin allows precise curing, ensuring consistent part quality and structural integrity.
Application：
Aerospace components：
Used in aircraft panels and engine parts, leveraging heat resistance and lightweight strength.
Ballistic protection：
Applied in armor plating and vehicle shields, utilizing impact absorption for defense applications.
Racing and sports equipment：
Utilized in race car chassis and helmet liners, balancing weight reduction and crash safety.
Specification:
| Weinuo Composites Epoxy Resin Systems | ||
| Resin Model | Resin Characteristics | Application Areas |
| WP~B1268 | Low temperature curing down to 80°C/3h is possible. | Low temperature curing or products with low temperature resistant cores, etc. |
| WP~H1655 | High temperature resistance, Tg can reach 178℃. | High-end carbon fibre wheels |
| WP~H2002 | High temperature resistance, Tg can reach 200℃. | Carbon fibre wheels, aerospace and other components |
| WP-H2002N | High temperature resistance, TG 210°C | Ultra-high temperature resistant epoxy series |
| WP~L1600 | Low-temperature curing for large-size, ultra-thick products. | Oversized parts such as wind turbine girder plates |
| WP-L1230 | Fast curing at 120°C for 30min | 3C industry, low-temperature and fast products. |
| WP~L5100 | Fast curing at 150°C/10min | Rapid curing products for drone paddles, shoe materials, automotive parts, etc. |
| WP~L5107 | 140℃/6min fast curing | 3C industry, products such as ultra-fast requirements, unfavorable transportation |
| WP~R1200 | Production of ultra-low gram prepregs | High-end carbon fiber rods, minimum 10 grams of prepreg |
| R1312(Winter) | Production of conventional 100 and 150 gram prepregs | Low-cost formulations for drone platens, fishing rods, tubing, etc. |
| R1312 | Production of conventional 100 and 150 gram prepregs | Drone platens, fishing rods, pipe industry, summer formulas |
| R1360 | Toughened resin, elongation at break can reach 5%, impact strength 72KJ/㎡. | Drones, baseball industry, products with high toughness requirements |
| R5600W3K | 3K apparent resin, clear, no white spots | Automotive parts, coil industry, exterior parts |
| R5601W3K | 3K apparent resin, transparent, no white spots, excellent workability | Automotive parts, coil industry, exterior parts |
| R5603W3K-F | 3K apparent resin, highly transparent, no white spots, Tg＞110°C | Automotive components, coil industry, high-end exterior parts |
| S1001 | Low viscosity standard epoxy | Carbon fiber rods, reels, high-end sporting goods |
| S3001 | Medium Viscosity Standard Epoxy | Carbon fiber rods, reel industry, high-end sporting goods |
| S5000 | High viscosity standard epoxy with excellent overall performance | High-end sporting goods, military products |
| S5001 | High viscosity standard epoxy with excellent overall performance | Carbon fiber bicycle, badminton, hiking poles, high-end fishing gear and other industries |
| S5001-Y | High-viscosity standard epoxy, tackified version, excellent overall performance | Carbon fiber bicycle, hiking poles, high-end sporting goods and other industries |
| S5003 | High viscosity standard epoxy, fast reaction speed, excellent overall performance | High-end carbon fiber products and products with a fast production tempo |
| S5100 | Medium to high viscosity standard epoxy, fast reaction speed, cost-effective | Lightweight products with low resin content, excellent maneuverability |
| S6000 | Ultra-high viscosity standard epoxy with excellent overall performance | M40/and above modulus fiber |
| CFR02-2 | High viscosity standard epoxy, fast reaction speed, excellent overall performance | High-end carbon fiber badminton racket and other products |
| R2600 | Low viscosity, fast response time | Molded sheets, shoe materials, golf clubs and other industries |
| 2100 | Halogen-free flame retardant, DIN5510 | Rail transportation, military products |
| WN-2120-1 | 150℃/5min curing 94V0 grade halogenated flame retardant | Battery box cover, 3C industry |
| 2201（100℃） | EN45545 R1 HL2 class flame retardant | Rail transportation, military products |
| 2201（120℃） | EN45545 R1 HL2 class flame retardant | rapid transit |
| 2201（150℃） | EN45545 R1 HL3 class flame retardant | rapid transit |
| 1072 | Halogenated 94V0 flame retardant | Industries requiring flame retardant and non-white appearance |
| 1076 | Halogen-free 94V0 flame retardant | 3C industry, high-end flame retardant products |
| B1280 | Low temperature 80 degrees curing halogen-free flame retardant, halogen-free 94V0 flame retardant | Low temperature curing flame retardant field |
| 1125 | Transparent resin with good adhesion, for winter use | Transparent products such as automobile exterior parts |
| R1208 | Small Gram Prepreg, Low Halogen | 3C industry |
| 1216 | Yellowing resistance, high transparency | Photovoltaic industry |
| S1087 | High modulus prepreg, resin modulus close to 3.5G | Bicycle industry |
